    Livestock Chicken Feed Manufacturing Plant , PLC Poultry Feed Production Line

    Livestock Chicken Feed Manufacturing Plant , PLC Poultry Feed Production Line

    Introduction

    This complete Livestock Feed Production Line is suitable for producing all kinds of feed pellets for various animals such as chicken, pig, cow, cattle, goat, rabbit etc.

    When using automatic line, two sections are needed, all of the sections is controlled the PLC computer program, which can save both the electric power and the manpower.

    Just use different size of ring die mould to produce different animal feed pellet according to the requirement of different animal and poultry.

    The replacement of the ring die mould is very easy.


    Animal Feed Production Line Process flow

    Raw Materials for Feed Pelletizing, Raw Material Grinding Process, Feed Material Mixing Process, Feed Pelletizing Process, Feed Pellet Cooling Process, Feed Pellet Crushing Process, Feed Pellet Screening and Grading Process, Feed Pellet Packing Process



    Automatic PLC Control System
    With the automatic PLC control system, the animal feed processing line is with high efficiency and convenient operation.
    1.Full automation of the complete production line
    2.Constant product quality at a high throughput rate
    3.Lower manpower requirements, less time cost
    4.Better monitoring of the production process

    Technical Parameters

    15-20 T/H Animal Feed Pellet Production Line
    No.Product nameModelQtyPower(kw)
    1. material receiving section
    104Bucket elevatorTDTG48/2825.5
    105granule material clean sieveSCY8010.75
    106permanent magneticTXCT251
    111rotary distributorTFPX.810.55
    2. material grinding section
    205Impeller feederSYLW311.50
    206Tear-circle hammer millSDH-ZW50C1132
    209seal screw conveyorSWLL2526.00
    210Impeller feederSYLW311.5
    211Tear-circle hammer millSDH-ZW80B190
    212Fan4-72-N04.5A111
    213pulse dust collectorTBLFa.421
    3. batching and mixing section
    311small material feeding1
    312pneumatic valveTZMQ32*321
    313 316

    Double shaft high efficient mixer
    Double shaft high efficient mixer

    SSHJ.2 SSHJ.41 118.5 30
    317LevelerRP1
    318Vibration hammer1
    319scrapper conveyorTGSU2513.00
    322powder material clean sieveSCQZ80111
    4. pelleting section
    404vibration pneumatic hammer4
    407Pellet machineSZLH4202220.00
    409counter-current coolerSKLN623.0
    410crusherSSLG20×170230
    412Fan4-72No6C230
    413dischargerSKL10002
    415Bucket elevatorTDTG40.2828
    416classic sieveSFJH12526
    5. packing section
    507automatic packing scaleSDBY-P2
    508seal conveyor machineTFKB4026
    510pulse dust collectorTBLFa.241
    511seal machinery10.75
    512Fan4-72-N04.5A17.50
    513pulse dust collectorTBLFa.301
    6.auxiliary system
    601Air compressor122.00
    602storage air tank1
    603Dryer1
    604liquid adding machineSYTV6313.00
    606Steam boiler system2T1


    animal feed production line
    Welcome contact us for more information !
